Specifications Material BK7, Fused Silica or Other Dimension And Tolerance 3x3, 5x5, 10x10, 12.7x12.7, 20x20, 25.4x25.4+0.0/-0.2mm or as requirement Thickness Tolerance ±0.2mm Clear Aperture >90% Flatness λ/[email protected] per 25mm range Surface Quality 60/40 or better Coating(Internal Reflectance and External Reflectance) Enhanced Aluminum or Protected Gold or other Metal Coating and Dielectric Coating on hypotenuse, two legs AR coated
Material
BK7, Fused Silica or Other
Dimension And Tolerance
3x3, 5x5, 10x10, 12.7x12.7, 20x20, 25.4x25.4+0.0/-0.2mm or as requirement
Thickness Tolerance
±0.2mm
Clear Aperture
>90%
Flatness
λ/[email protected] per 25mm range
Surface Quality
60/40 or better
Coating(Internal Reflectance and External Reflectance)
Enhanced Aluminum or Protected Gold or other Metal Coating and Dielectric Coating on hypotenuse, two legs AR coated
